February 10, 2011

Duckweed species native to Cache Valley (northern Utah)

Lemnacea (common name duckweed) grows naturally in almost every region with a growing season of at least five months. Most studies involving duckweed take place in climates with 9-10 month growing seasons. More rare are the duckweed studies taking place in regions like Cache Valley with only 5-7 month growing seasons [Culley, 1981]. Duckweed is a C3 plant—which helps grow in colder climates with shorter growing seasons. Since water freezes in the winter and duckweed floats on water, it does best in warmer climates. Nonetheless, of the four principal duckweed genera three are still found in Cache Valley. There are three principal species from this genera in Cache Valley, all of which are reported to be cold tolerant. The duckweed plants growing in Cache Valley Utah include Lemna turionifera (or L. minor), Wolffia Borrealis, and Spirodela Polyrhizza. Duckweed’s native presence in Cache Valley, its resilience to temperate climates, and its fast growth rates make it promising for nutrient removal.

The location of the Cache Valley duckweed varies depending on the species. L. minor/turionifera and W. borealis grow in a mixed culture on the Wellsville Municipal Sewage lagoons (56 acres). L. minor is more predominant in the field than Wolffia. The Wellsville lagoons receive some sheltering from wind due to their location in a recessed area bordered by trees along the Little Bear River (Fig. 1, left). These two species are only found in the parts of the Logan Wastewater lagoons that are protected from wind (i.e. culverts, chlorination basin, and wetlands). The majority of the 460 acre Logan lagoons are not protected from wind and do not contain duckweed (Fig. 1, right). The third Cache Valley species, S. Polyrhizza, can be found up Logan Canyon near third dam on the north side of the highway. These duckweed species, especially L. minor have adapted to temperate climates like that of northern Utah [Culley; Landolt 1986 p.421]. During the three years this study took place, full-duckweed coverage on the Wellsville lagoons occurred at the first part of May and continued until about the third week in November. The wastewater lagoons freeze during the winter forcing the duckweed plants into dormancy; however, duckweed fronds appear in the water at the first sign of ice melting off the lagoons in the Spring and occasionally on top of the ice in small puddles of water during particularly warmer periods during winter (Fig. 2).

The duckweed species native to Cache Valley need to tolerate temperate climates with cold winters. Spirodela polyrhizza, Wolffia borealis, and Lemna turionifera all develop special fronds called "turions" when the weather starts to cool. Turions are overwintering buds rich in starch. In the case of L. turionifera they look like single dark green fronds. In the case of W. borealis, they look like tiny spherical balls. Turions have a higher specific gravity than water. During winter, turions sink down into the sediments and then emerge under warmer conditions thus enabling them to survive freezing weather (Landolt, 1986, pp.421). Unlike the other three species, Lemna minor produces "resting fronds." Resting fronds look like the turions from L. turionifera but they do not sink to the sediment. The resting fronds also have a specific gravity > 1 which enables them to sink below the water surface and avoid being frozen at the surface by ice.

Figure1 : Duckweed growing atop 56 acres of Wellsville Municipal Sewage Lagoons which sits in a basin, but not growing atop 460 acres of Logan City lagoons.

Figure 2: (Left) L. minor and Wolffia duckweed species appearing immediately after the ice melts ca. March and April. (Right) L. Turionifera turions or L. minor "resting fronds" floating on 3 cm. water puddle above the ice on Feb. 4, 2011, following unusual rainy winter weather.

Lemnaceae species increase in size from Wolffia, L. minor, and S. polyrhizza species, respectively. Several factors contribute to the size of the fronds. Daughter fronds in lab studies are often smaller than the mother fronds (Al-Nozaily) which needs to be considered when basing growth rate on frond count. As plant density increases frond size often decreases. Landolt listed other factors contributing to an increase in frond size, including: increased light intensity; increased light duration; addition of sugar; increased nitrogen, phosphorus, potassium, calcium, and magnesium concentrations (which can also decrease frond size if too high); and increased temperature (Landolt, 1986, pp.36-37). Typically, full-size fronds for Wolffia, L. minor, and S. Polyrhizza range from 0.5-1mm, 3-5mm, and 1-1.5cm, respectively. L. minor fronds ranged in sizes depending on the development stage of the frond (i.e. whether a bud to a frond or fully separated frond w/ or w/o buds). Figure 3 show how L. minor fronds were characterized depending on development. The Lemnaceae species used in these laboratory experiments had a density of 815ug/ml (s.g. 0.82).

Figure 3: Characterization and digital imaging of L. minor and Wolffia fronds

Table 1: Characterization of L. minor fronds by area, mass, and dimensions

Table 2: Characterization of Wellsville duckweed by elemental composition

Some aquatic species tolerate cold climates as well or better than duckweed but unlike duckweed they do not currently grow on Wellsville nor Logan wastewater lagoons in Cache Valley. Watercress (Nasturtium officinale), have the ability to grow during the harsh Cache Valley winters provided that they are near flowing water like springs [Michaelis, 1976; personal observation]. Watercress grows during the winter in a canal running adjacent and north of Canyon Road in Logan, Utah, near the Utah Water Research Laboratory. Duckweed favors calm water, unfortunately, this turns to ice and limits the duckweed growing season to approximately six months in Cache Valley.

Azolla and pennywort have also been recommended as frost tolerant aquatic plants; unfortunately, their growth rates are lower than duckweed’s and they are not yet established on Cache Valley lagoons [personal correspondence with Louis Landesman, 2/12/09]. Duckweed species already grow on wastewater in Cache Valley and the literature about them is prolific. It is doubtful any other floating aquatic plant could outperform the duckweed since ice formation, not frost resistance, is the limiting factor of winter growth on wastewater lagoons in Cache Valley.

More on duckweed inhibitors

A follow-up on factors inhibiting duckweed growth:

1. Fungi--probably pythium fungi, cause plant tissues to deteriorate consequently converting duckweed into a meal for micro-organisms (Suren, 1989). Pythium blight starts small and spreads until it eventually infects all the duckweed. (Rejmankova, 1986; website http://www.mobot.org/jwcross/duckweed/duckweed-pests.html)

Methods to prevent and/or eliminate fungi:

a) Fungicide. Apply fungicide like Ridomil Gold EC at a rate of 0.3uL/L-nutrient solution. To do this, you can make up "Subdue" solution (0.3ml-Ridomil GoldEC/L) and then apply "Subdue" solution at a rate of 1mL-"Subdue"/L-nutrient solution. I only had to apply this fungicide to my 100L reactor once to get rid of all the fungi. I had no problem with the fungi until I began to experiment with lower duckweed densities (below 30g(dry)/m^2) and low nutrient solutions (<1ppm P and N). After the fungi reappeared following the latter growth conditions, I accidentally applied Ridomil GoldEC at a rate of 1mL/L-soln. Oops! I came back the next day to find a room that smelled like paint thinner and a reactor void of duckweed (all of it sunk to the bottom of the reactor).
b) Silicon. Add silicon to nutrient solution which might have the effect of "toughening" cell tissue to resist fungi and disease. The USU Crop Physiology Laboratory has noticed that their hydroponic solutions containing silicon are more resistant to disease. They have a recipe to produce 2KOH + SiO2 --> K2SiO3 + H2O. The instructions to make this are as follows: First, dissolved 44.9g KOH in ~3.5L distilled water; Second, stir until clear (~15 min.); Third, add 24 g SiO2 (fumed silica--before to use a fume hood and/or filter mask); Fourth, stir until clear (~4-8 hrs.); and Fifth, bring volume to 4 L. Note: they have also noticed disease resistance by simply adding chunks of potassium silicate glass to the sediment to supply the silicon.

Figure 1: Duckweed fronds with early onset of fungi infestation.

Figure 2: Duckweed fronds 3-7 days after Fig. 1.

Figure 3: Duckweed fronds completely infected by fungi and being decomposed by micro-organisms.

c) Temperature. Regarding fungi with duckweed and temperature effect, Elias Landolt wrote:
8. Fungi. The hypochytridiomycetes Reessia amoeboides and Reessia lemnae live endobiotically in dying Lemnacea, accoding to Wagner (1969) and Kandeler (1979). Colbaugh (1981) reports of a lethal foliar blight of Lemnaceae in water cultures, which is caused by the oomycete Pythium aphanidermatus. The reduction occurs due to foliar blight and dying of the fronds. Greatest foliar blighting activity occurs at temperatures of 24'C and 27'C (better than at 18'C, 21'C, and 30'C). Rejmankova et al. (1986) isolated Pythium myriophyllum from L. gibba growing in a dairy farm of Louisiana. The authors were able to show that this gungus is the cause of duckweed kills. Under natural conditions and temperatures above 22'C the amount of duckweeds killed by the gungus grows exponentially and the whole stand dies within several days. Six species of lemnaceae have been tested in the laboratory: L. gibba, L. minor, and S. polyrrhiza proved to be most susceptible to the fungla infection. L. valdiviana showed more resistance whereas L. aequinoctialis and S. punctata never exhibited symptoms of desease. Optimum temperature for infection was about 32'C. It is interesting to note that the susceptibility to a fungal disease might be a factor limiting the distribution of certain Lemnaceae species. Rhizoctonia solani is able to infect L. minor, but the plants only get small irregular lesions (Joyner and Freeman 1973). A smut, tracya lemnae, is known from Spirodela (Fisher 1953, Zogg 1985).
Citer from (Landolt, 1986, pp.194-195)
2. Algae--when duckweed densities are low, then algae grow by the light that otherwise would be absorbed by floating duckweed. Algae grows in the water column and the surface. It can attach to duckweed tissue. I've personally observed that air bubble form underneath duckweed in solution with algae--cutting off its interface directly with the water column. Elias Landolt said:
Algae are most competitive with Lemnaceae in nutrient-rich waters. Filiform algae, which form dense mats on the surface of the water (e.g. Spirogyra) especially can prevent Lemnaceae from spreading successfully. Very often, the algae cover is raised by development of gas, thus breaking the contact of the Lemnaceae with the water and causing the drying of fronds.
Cited from (Landolt, 1986, p.203)
Further reading: (Szabo, 1998/2003/2005; Roijackers, 2004; Smart, 1985)

Ways to reduce/eliminate the growth of algae with duckweed include:

a) rinse duckweed in 0.05% sodium hypochlorite soln. (aka. bleach)--this is comparable to chemotherapy for duckweed plants and it's a matter of "survival of the fittest." You only need to rinse for 5-30 seconds. I tried this procedure once and rinsed fronds for 30 seconds which destroyed virtually all of the fronds (and algae).
b) as part of "a" growing cultures in the lab should be as aseptic as possible (i.e. autoclave or filter nutrient solution, laminar flow hood, autoclaved glassware, etc.). This is difficult for me to do which is probably why I seem to always end up with algae showing up.
c) foil or dark material to cover all but the surface of the growing vessel reducing the light available for algae growth beneath the water suface.
d) maintain a crop density of at least 20-30g(dry)/m^2; anything lower than this allows too much light to pass through the duckweed cover.
e) filter using sand and/or diatomaceous earth (Naghavi, 1986)
f) periodic spraying ponds with algicide copper sulphate at a concentration of 2mg/L; spray at noon when temperatures and algae concentrations are high. This algicide procedure was used to remove filamentous alga Oedognium (Edwards, 1992).

Figure 4: Algae attaching to pythium fungi-infected duckweed.

Figure 5: Healthy duckweed fronds and roots without algae, for bioassay

Figure 6: Signs of algae infestation (progressively worse L to R).

Figure 7 (top-bottom pairs): Logan City wastewater w/o and w/ chlorine;
Wellsville City wastewater; Hydrosol nutrient solution.

Figure 8: Bioassays (APHA Std. Method 8211) by frond count. Logan w/ and w/o chlorine.

Figure 9: Bioassay method 8211 Hydrosol and Wellsville City ww solutions.
Figure 10: Bioassay method 8211; 3-5 days (typ. 96 hrs.); Wellville City and Logan City w/Cl ww.

Figure 11: Duckweed plants following bioassay;
removed one-by-one for frond/colony counting.

Figure 12: More duckweed plants following bioassay;
removed one-by-one for frond/colony counting.

Figure 13: Bioassay results comparing effect of nutrient solutions and chlorination on duckweed growth. It appears that nutrient solution has a larger effect on duckweed growth than whether or not it has been chlorinated (see below).

3. Chlorine. Chlorine was investigated as a potential growth inhibitor in duckweed . Duckweed was collected first collected from the chlorination basin and wastewater collected just following the chlorination basin. After noticing that this duckweed had lower growth rates than the Wellsville City duckweed, a series of bioassays were conducted to compare the effect of chlorination on duckweed growth. Results showed that nutrient solution had a greater effect on growth rate than chlorination. In some cases, duckweed on chlorinated Logan City wastewater (ww) experienced higher growth than on non-chlorinated ww; nonetheless, both Hydrosol nutrient solution and raw Wellsville City ww produced higher growth rates than Logan City ww. The lower growth rates on Logan City ww are likely due to the algae competition. Fig 7 above shows the relative amount of algae in Logan City ww compared to the other solutions. One report showed that macrophyte growth can be inhibited by total residual chlorine concentrations greater than 0.05ppm (TRC) (Watkins, 1984). Tap water is not recommended for producing nutrient solution probably due to TRC concentrations. TRC in Logan City tap water at the UWRL is below 0.05mg-TRC/L. Residual chlorine is believed to have negligible effects on the duckweed growth in this study.

Figure 14: Boxplots showing effect of nutrient solution and chlorination on duckweed growth. Results show that duckweed growth slows over time (i.e. harvest more frequently) and chlorination effect is negligible.

4. pH--Hydroponic solutions typically recommend low pH (4.5-6) because more nutrients are available in solution. As pH rises, so does the likelyhood that nutrients like phosphorus, iron, and calcium will precipitate from solution. Competition between algae and duckweed was discussed earlier. One of the advantages algae has over duckweed is the ability to tolerate higher pH. Algae removes carbonate alkalinity, respires oxygen, and add hydroxyl alkalinity to the water, thus rising pH values. It is not uncommon for algae rich waters to have pH value ca. 9.3 or higher. Prior to installing pH control (via solenoid, controller, and CO2 gas similar to the system described by Bugbee) the pH in the 100L laboratory reactors reached as high 11 (8.3-9.6 typical). On 11 May 2010, the pH at the Wellsville City Municipal Sewage Lagoons (WMSL) ranged from 7.37 near the first pond (influent) to 8.09 in the fourth/final pond (effluent). As pH increases, an interesting phenomenon between duckweed species occurred in the laboratory. At the WMSL the dominating duckweed species is L. minor (possibly L. turionifera or both) and the less abundant species is W. borealis. However, once brought into the lab and grown indoors on increasingly high pH water then the balance between the two species shifted so that W. borealis became almost 100% dominant. In our case, pH most likely produced the species shift, but harvesting methods also lead to dominating Wolffia cultures since they are easily suspended in the water column and small enough evade harvesting--leading to its abundance and the removal of other larger species (Culley, 1981).


Suren, A.M., "Histological changes in macrophyte tissue during decomposition," Aquatic Botany, 33 (1989) 27-40.

Rejmankova, E., "Dynamics of fungal infection in duckweeds (Lemnacea)", Veroff.Geobot.Inst.ETH, Zurich, 87 (1986), pp 178-189.

Landolt, E. (1986): The family of lemnaceae-a monographic study. Vol. 1 of the monograph: Morphology; karyology; ecology;geographic distribution; systematic position; nomenclature; descriptions. Published in the "Veroffentilichungen des Geobotanischen Institutes ETC, Stiftung Rubel, Zurich." This is also listed as vol. 2 (No. 71) of publications on "Biosystematic investigations in the family of duckweeds Lemnaceae."

Szabo, S., et al., "Influences of nine algal species isolated from duckweed-covered sewage miniponds on Lemna gibba L.," Aquatic Botany 60 (1998) pp189-195.

Szabo, S., et al., "A simple method for analysing the effects of algae on the growth of Lemna and preventing algal growth in duckweed bioassays," Arch. Hydrobiol. 157 (4) pp.567-575 (2003).

Szabo, S., et al., "The strength of limiting factors for duckweed during algal competition," Arch. Hydrobiol. 164 (1) pp. 127-140 (2005).

Roijackers, R., et al., "Experimental analysis of the competition between algae and duckweed," Arch. Hydrobiol. 160 (3) pp. 401-412 (2004).

Smart, R.M., et al., "Laboratory culture of submersed freshwater macrophytes on natural sediments," Aquatic Botany, 21 (1985) pp251-263.

Naghavi, B., et al., "Algae removal by fine sand/silt filtration," Wat. Res. (1986) Vol 20, No. 3, pp. 377-383.

Edwards, P., et al., "Cultivation of Duckweeds in septage-loaded earthen ponds," Bioresource Technology, 40, pp.109-117 (1992).

Watkins, C., "The toxicity of chlorine to a common vascular aquatic plant," Water Res. 8 (1984) pp. 1037-1043.

Culley, D.D., et al., "Production, chemical quality, and use of duckweed (Lemnaceae) in aquaculture, waste management, and animal feeds," Journal of the World Mariculture Society, Vol. 12 (2), pp.27-49 (1981).
